GGE-OR108 8 ways ofc transmitter and receiver
Performance Characteristics
1.Model Number: GGE-OR108; Brand name: GreenGo
2.Aluminum die-cast outdoor housing
3.8 outputs, output level each 80dBuV(-5~+2dBm).
4.Special built-in RF AGC control
5.2 kinds of power supply way.( 12VDC power in; Reverse power from STB-12V via Power insertor)
6.Import Chipset MMIC circuit, high gain and super linearity & non-linearity performance
7.Lower power consumption
Technical Specification
|
Number Item |
Unit |
Description |
Remark |
|
| Optical Parameters | ||||
|
1 |
Wavelength |
nm |
1290~1600 |
|
|
2 |
Optical input range |
dBm |
-16~+2 |
|
|
3 |
Optical Return Loss |
dB |
＞45 |
|
|
4 |
C/N |
dB |
＞51 |
|
|
5 |
CTB |
dB |
＞65 |
|
|
6 |
CSO |
dB |
＞60 |
|
|
7 |
Flatness |
dB |
≤±0.75 |
|
|
8 |
Optical Connector Type |
|
SC/APC or FC/APC |
|
| RF Parameters | ||||
|
9 |
Frequency Range |
MHz |
45~862 |
|
|
10 |
Input Impedance |
Ω |
75 |
|
|
11 |
Return Loss |
dB |
＞14 |
|
|
12 |
RF Output level |
dBuV |
80 |
-5~+2 |
|
13 |
Output test |
dB |
-20 |
|
| General Parameter | ||||
|
14 |
Power Input Voltage |
|
12V 1A |
adaptor |
|
15 |
Dimensions(Node) |
mm |
157(L)*115(W)*73(H) |
|
| Dimensions(Insertor) |
mm |
94(L)*94(W)*24(H) |
||
|
16 |
Package |
|
1piece/Box. 10pcs/Ctn |
|
|
17 |
G.W |
kg/Ctn |
13.00 |
|
