IP converter and multiplexer
Short Description:
Product Overview
NN0201R products are our company’s latest research and development of a digital TV front-end equipment, It can realize IP conversion and program multiplexing output. 1 Gigabit (RTMP/HTTP/RTSP/HLS/SRT protocol ) input and 1 Gigabit (UDP/RTP protocol) input, 1 Gigabit output (MPTS/SPTS over UDP/RTP protocol) ; supports 2 ASI input and 4 ASI output.Supports transcoding of program audio. The device has excellent performance and flexible configuration, using 1U chassis, compact structure, easy to install and use. A single device integrates a whole set of front-end system functions, which is very suitable for a variety of new generation digital TV broadcasting systems.
System function diagram
Product features
l Provides 3 gigabit port input/output(2 port input,1 port output)
l Supports RTMP/HTTP/RTSP/HLS/SRT/UDP input( DATA 1 ) , UDP/RTP input( DATA 3 )
l Supports 1 gigabit port 4 MPTS/ 512 SPTS output (DATA2) over UDP/RTP
l Supports transcoding of program audio (DATA1:MP2/AAC)
l Supports 2 ASI input
l Supports 4 ASI output
l Using 1U chassis, a single device integrates a set of front-end device functions, saving installation and wiring space
l Supports network management (Web)
l Support online upgrades
Streaming media output(DATA1)
| Version：4.19.232-33.31-0.1-20240701
Date：202407 Mode：Received stream |
||||||||||||
|
Protocol |
Input Format |
Video |
Audio |
TS bitrate |
Channels |
Total output bitrate |
||||||
|
RTMP |
H264+AAC(LC) |
V:6Mbps |
A:128Kbps |
TS:6.5Mbps |
CH:60 |
BITRATE:390M |
||||||
|
HTTP |
H264+AAC(LC) |
V:6Mbps |
A:128Kbps |
TS:6.5Mbps |
CH:60 |
BITRATE:390M |
||||||
|
HLS |
H264+AAC(LC) |
V:6Mbps |
A:128Kbps |
TS:6.5Mbps |
CH:60 |
BITRATE:390M |
||||||
|
RTSP |
H264+AAC(LC) |
V:6Mbps |
A:128Kbps |
TS:6.5Mbps |
CH:60 |
BITRATE:390M |
||||||
|
SRT |
H264+AAC(LC) |
V:6Mbps |
A:128Kbps |
TS:6.5Mbps |
CH:42 |
BITRATE:270M |
||||||
| Version：4.19.232-33.35-0.1-20240903
Date：202408 Mode：Audio transcoding Testing Protocol：UDP/HTTP |
||||||||||||
|
TS bitrate |
Video |
V bitrate |
Source audio format |
A bitrate |
Target audio format |
Audio channels |
||||||
|
TS:6.5Mbps |
H264 |
V:6Mbps |
AC3 |
A:128Kbps |
MP2 |
CH:30 |
||||||
|
TS:6.5Mbps |
H264 |
V:6Mbps |
AAC(LC) |
A:128Kbps |
MP2 |
CH:30 |
||||||
|
TS:6.5Mbps |
H264 |
V:6Mbps |
AC3 |
A:128Kbps |
AAC(LC) |
CH:12 |
||||||
|
TS:6.5Mbps |
H264 |
V:6Mbps |
MP2 |
A:128Kbps |
AAC(LC) |
CH:20 |
||||||
| Note:
1. This test is the test result of the device in a relatively ideal network environment. When designing the front-end system, it is necessary to consider the influence of the actual working environment, such as the network environment and other devices in the network. 2. Each program in the test contains only one audio.The target format for audio is optional MP2/AAC.Enabling audio transcoding consumes performance. |
||||||||||||
Specifications
| Input |
2 Gigabit IP inputs (DATA1:RTMP/HTTP/RTSP/HLS/SRT/UDP input; DATA3: UDP/RTP input) |
|
|
2 ASI input |
||
| Output |
1 Gigabit output,DATA2: 4 MPTS/ 512 SPTS,UDP/RTP output |
|
|
4 ASI output |
||
| System |
Web/NMS |
|
|
Chinese/English |
||
| Miscellaneous |
Dimensions |
482mm×300mm×42mm |
|
Weight |
4kg |
|
|
Temperature |
0~45℃(Operation)；-20~80℃(Storage) |
|
|
Voltage range |
AC100~240V，50/60Hz |
|
|
Power consumption |
<30W |
|
Product structure
|
Number |
Interface Overview |
|
1 |
LCD |
|
2 |
Keys and indicator lights |
|
3 |
NMS: NetworkManagementSystem |
|
|
DATA1:1G port IP input ,RTMP/HTTP/RTSP/HLS/SRT/UDP protocol,
DATA2:1G port IP output ,4 MPTS/ 512 SPTS over UDP/RTP protocol DATA3:1G port IP input, UDP/RTP protocol |
|
4 |
ASI port ( 2 input and 4 output ) |
|
5 |
Power Switch |
